1 PXW – FS7 Mark II Cine Camera

Overview

The Sony PXW-FS7M2 is not a direct replacement to the original FS7, but rather a separate offering in the Sony large sensor/cinema camera line. Key features include:

8.8MP 4K S35 CMOS sensor
10-bit 4:2:2 in 4K DCI
Capture up to 60p in 4K DCI or 180p in FHD
Newly designed locking e-mount plus an electronic variable ND

What’s Different? Since this is not a replacement for the FS7, the most important question is not what’s new, but instead what makes it different from the original. The biggest improvements include a brand new, first-of-its-kind locking E-Mount, Electronic Variable ND (as seen on the FS5), and general improvements to the construction and user experience.

Reinforced Locking E-Mount. Now instead of docking and twisting, just insert the lens without rotating and turn the locking ring. The new locking E-Mount is a part of a brand new reinforced camera front that has better support for cine lenses.

Electronic Variable ND. The Electronic Variable ND works in one of three different ways. The first is like a conventional ND filter wheel, with 4 set positions you can swap between. Second, you can rotate the knob and ease through seven stops of filtration like a lens front mounted variable ND. Lastly, the FS7 Mark II’s auto ND function allows you to lock your shutter speed and aperture despite changing lighting environments.

Refined Build Quality. The FS7 II features a tool-less design, meaning you can make adjustments to the Smart Grip or the viewfinder on the fly without having to pull out a screwdriver. The number of user-programmable buttons has increased from 6 to 10, giving operators a greater level of control.

High Dynamic Range. The FS7M II uses the same super35 as the original model, which means 14 stops of dynamic range. The big upgrade in the II is the addition of the REC BT.2020 color space with full support HDR imagery.

Please note that XQD CARDS OR XQD CARD READERS are NOT included!

HTTPS://BLOG.LENSPROTOGO.COM/2017/03/27/IS-THE-SONY-FS7-MARK-II-WORTH-THE-UPGRADE-4/

HTTPS://BLOG.LENSPROTOGO.COM/2017/04/04/THINGS-YOU-SHOULD-KNOW-ABOUT-THE-FUJINON-MK-18-55-T2-9-CINE-ZOOM-3/

Specification

Image Device Super 35mm Single-Chip Exmor CMOS

Effective Picture Elements 17:9 4096 (H) x 2160 (V)

16:9 3840 (H) x 2160 (V)

Signal-to-Noise Ratio 57 dB (Y)

Sensitivity 2000 lx, 89.9% reflectance

T14 (3840 x 2160/23.98p mode 3200K)

ISO Sensitivity

ISO 2000 (S-Log3 Gamma D55 Light source)

Minimum Illumination 0.7 lux: +18 dB,23.98p,Shutter OFF,ND Clear, f/1.4

Signal System NTSC / PAL

Built-in Filters Clear, 1/4, 1/16, 1/64

LCD Monitor 3.5" / 8.8 cm

Approx: 1.56M dots

Speaker Monaural

Shutter Speed 1/3 to 1/9000 of a sec

White Balance Preset

Memory A

Memory B (1500K-50000K)/ATW

Gain Selection -3, 0, 3, 6, 9, 12, 18 dB, AGC

Gamma Curve STD

User

S-log3

Shooting Formats 4K 4096 x 2160

12-bit raw

UHD 3840 x 2160

10-bit 4:2:2 XAVC-I

8-bit 4:2:0 XAVC-L

2K 2048 x 1080

12-bit raw

HD 1920 x 1080

10-bit 4:2:2 XAVC-I

10-bit 4:2:2 XAVC-L

MPEG2 4:2:2

HD 1280 x 720

MPEG2 4:2:2

Audio Recording Format LPCM 24 bits, 48 kHz, 4 channels (Recording/Playback 2 channels)

Recording Formats XAVC-I QFHD MPEG-4 H.264/AVC

59.94P CBG, bit rate 600 Mb/s

50P CBG, bit rate 500 Mb/s

29.97P CBG, bit rate 300 Mb/s

23.98P CBG, bit rate 240 Mb/s

25P CBG, bit rate 250 Mb/s

XAVC-I HD MPEG-4 H.264/AVC

59.94P VBR, maximum bit rate 222 Mb/s

50P VBR, maximum bit rate 185 Mb/s

59.94i VBR, maximum bit rate 111 Mb/s

50i VBR, maximum bit rate 112 Mb/s

29.97p VBR, maximum bit rate 111 Mb/s

23.98p VBR, maximum bit rate 89 Mb/s

25p VBR, maximum bit rate 112 Mb/s

XAVC-L QFHD MPEG-4 H.264/AVC

59.94p/50p mode: VBR, maximum bit rate 150 Mb/s

29.97p/23.98p/25p mode: VBR, maximum bit rate 100 Mb/s

XAVC-L HD 50 MPEG-4 H.264/AVC

VBR, maximum bit rate 50 Mb/s

XAVC-L HD 35 MPEG-4 H.264/AVC

VBR, maximum bit rate 35 Mb/s

XAVC-L HD 25 MPEG-4 H.264/AVC

VBR, maximum bit rate 25 Mb/s

MPEG-2 Long GOP

CBR, maximum bit rate 50 Mbps, MPEG-2 422P@HL

XAVC-I QFHD 3840 x 2160/ 59.94p, 50p, 29.97p, 23.98p, 25p

XAVC-I HD
